Pictures for reference only, please check the datasheet

NYC222STT1G

Name: NYC222STT1G
Brand: Littelfuse
SKU: F001-NYC222STT1G-8-A-0000-X-Y-863-NYC222STT1G
Availability: InStock
Rating: 5 (2 reviews)

Manufacturer:

Littelfuse

Mfr. Part #:

NYC222STT1G

Walsoon Tech #:

F001-NYC222STT1G-8-A-0000-X-Y-863-NYC222STT1G

Description:

SCR 1.5A 50V SOT-223

Delivery:

Payment:

PayPal, Credit Card, Wire Transfer, Western Union

Add To BOM

In stock

Tips: Best quotation will be offered within 24h, upon receiving your quick RFQ.

Quick RFQ

Sell your excess inventory

NYC222STT1G Details
Packing And Shipping
Payment Method
Quality Control

Littelfuse,NYC222STT1G is available at Walsoon Tech.100% original and new guarantee. If comprehensive data for NYC222STT1G to optimize the supply chain, including costdown, time-saving, cross references, parametric, counterfeit risk, alternative components, obsolescence management forecasts is expected, please contact our professional team.

Specification

Package	SOT-223
Gate trigger voltage	800mV
工厂最小包装	1000
寿命周期	量产
ROHS	no
Holding Current	5mA
Gate trigger current	0.2 mA
Maximum Breakover Current IBO	15 A
Max. gate threshold reverse voltage	5 V
Operating Temperature Range	- 40 C~+ 110 C
Height	1.57 mm
Length	6.5 mm
Width	3.5 mm
Off-state voltage （Vdrm）	50 V
Transistor type	SCRs
Termination type	SMD/SMT
On-state rms current	1.5 A
