PM5022S-220M-RC

Name: PM5022S-220M-RC
Brand: Bourns
SKU: F004-PM5022S-220M-RC-21-A-0000-X-N-118-PM5022S-220M-RCTR-ND
Availability: InStock
Rating: 5 (2 reviews)

Manufacturer:

Bourns

Mfr. Part #:

PM5022S-220M-RC

Walsoon Tech #:

F004-PM5022S-220M-RC-21-A-0000-X-N-118-PM5022S-220M-RCTR-ND

Description:

22uH 20% 18.3mm*14mm*7.1mm 53mΩ 3A 贴片

Delivery:

Payment:

PayPal, Credit Card, Wire Transfer, Western Union

Add To BOM

In stock

Tips: Best quotation will be offered within 24h, upon receiving your quick RFQ.

Quick RFQ

Sell your excess inventory

PM5022S-220M-RC Details
Packing And Shipping
Payment Method
Quality Control

Bourns,PM5022S-220M-RC is available at Walsoon Tech.100% original and new guarantee. If comprehensive data for PM5022S-220M-RC to optimize the supply chain, including costdown, time-saving, cross references, parametric, counterfeit risk, alternative components, obsolescence management forecasts is expected, please contact our professional team.

Specification

Height	7.1mm
DC Resistance DCR	53mΩ
Termination type	贴片
Inductance Value	22uH
Tolerance	20%
Operating Temperature-Max	125℃
Operating Temperature-Min	-40℃
Rated Current	3A
Saturation current	6.2A
Length	18.3mm
Width	14mm
Operating Temperature Range	-40°C~125°C
工厂最小包装	250
寿命周期	量产
ROHS	yes
Brand	Bourns
Rated Current (DC current)	6 A
Resonant frequency	16MHZ
shielding	屏蔽
--	铁氧体
