Pictures for reference only, please check the datasheet

CMT-8109

Name: CMT-8109
Brand: Triad Magnetics
SKU: F002-CMT-8109-731-A-1715-X-N-53869339
Availability: InStock
Rating: 5 (2 reviews)

Manufacturer:

Triad Magnetics

Mfr. Part #:

CMT-8109

Walsoon Tech #:

F002-CMT-8109-731-A-1715-X-N-53869339

Description:

Common Mode Chokes Dual 30000uH 1kHz 2.3A 0.33Ohm DCR Thru-Hole Carton

Delivery:

Payment:

PayPal, Credit Card, Wire Transfer, Western Union

Add To BOM

In stock

Tips: Best quotation will be offered within 24h, upon receiving your quick RFQ.

Quick RFQ

Sell your excess inventory

CMT-8109 Details
Packing And Shipping
Payment Method
Quality Control

Triad Magnetics,CMT-8109 is available at Walsoon Tech.100% original and new guarantee. If comprehensive data for CMT-8109 to optimize the supply chain, including costdown, time-saving, cross references, parametric, counterfeit risk, alternative components, obsolescence management forecasts is expected, please contact our professional team.

Specification

Package	1.45 in1.35 in0.8 in
Rated Current	2.3 A
工厂最小包装	1
寿命周期	量产
ROHS	no
Operating Temperature Range	-55°C~105°C
Qualification level	ESD
Length	1.45 in
Width	1.35 in
Termination type	通孔
Height	0.8 in
DC Resistance DCR	330 mOhms
Inductor@frequency	30 mH
