Pictures for reference only, please check the datasheet

BD682G

Name: BD682G
Brand: ON
SKU: F002-BD682G-4-A-2301-X-N-85965171
Availability: InStock
Rating: 5 (2 reviews)

Manufacturer:

Mfr. Part #:

BD682G

Walsoon Tech #:

F002-BD682G-4-A-2301-X-N-85965171

Description:

Trans Darlington PNP 100V 4A 40000mW 3-Pin(3+Tab) TO-225 Box

Delivery:

Payment:

PayPal, Credit Card, Wire Transfer, Western Union

Add To BOM

In stock

Tips: Best quotation will be offered within 24h, upon receiving your quick RFQ.

Quick RFQ

Sell your excess inventory

BD682G Details
Packing And Shipping
Payment Method
Quality Control

ON,BD682G is available at Walsoon Tech.100% original and new guarantee. If comprehensive data for BD682G to optimize the supply chain, including costdown, time-saving, cross references, parametric, counterfeit risk, alternative components, obsolescence management forecasts is expected, please contact our professional team.

Specification

Pd-Power Dissipation	40 W
Collector-emitter voltage	100 V
Package	SOT-553
Collector Current Ic	4 A
工厂最小包装	500
寿命周期	量产
ROHS	no
Transistor polarity	PNP
Height	11.04 mm
Width	2.66 mm
Collector-Base Voltage VCBO	100 V
Termination type	SMD/SMT
Maximum collector cut-off current	200 uA
发射极 - 基极电压 VEBO	5 V
Operating Temperature Range	- 55 C~+ 150 C
Length	7.74 mm
